Description

• Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly*
• Miniature size and wall-mounted design make it easy to deploy and move flexibly
• Easily expand wireless coverage at a push of Range Extender button
• Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
• Tether App allows easy access and management using any mobile device
• LED Control function includes a Night Mode for peaceful sleep
• HARDWARE FEATURES
• Plug Type EU, UK, US
• Interface 1 * 10/100M Ethernet Port (RJ45)
• Button RE (Range Extender) Button, Reset Button
• Power Consumption About 3W
• Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Dimensions ( W x D x H ) 4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)
• Antenna 2 * internal
• WIRELESS FEATURES
• Frequency 2.4~2.4835GHz
• Signal Rate 11n: Up to 300Mbps (dynamic)
• 11g: Up to 54Mbps (dynamic)
• 11b: Up to 11Mbps (dynamic)
• Reception Sensitivity 270M: -68dBm@10% PER
• 130M: -68dBm@10% PER
• 108M: -68dBm@10% PER
• 54M: -68dBm@10% PER
• 11M: -85dBm@8% PER
• 6M: -88dBm@10% PER
• 1M: -90dBm@8% PER
• Transmit Power < 20 dBm (EIRP)
• Wireless Modes Range Extender
• Wireless Functions WMM (Wi-Fi Multimedia)
• Wireless MAC Address Filtering
• Wireless Statistic
• Domain Login Function
• Wireless Security 64/128/152-bit WEP
• WPA-PSK / WPA2-PSK
• OTHERS
• Certification RoHS
• Package Contents 300Mbps Universal Wi-Fi Range Extender TL-WA850RE
• RJ-45 Ethernet Cable
• Resource CD
• Quick Installation Guide
• System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
• Environment Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
